    IEC60587 Plastic Testing Machine High Voltage Tracking Index Leakage Current

    Ask Lasest Price
    Brand Name : Daxian
    Model Number : DX8427
    Certification : IEC60587-2007, ASTM D2303
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 5 sets per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    IEC60587 Plastic Testing Machine High Voltage Tracking Index Leakage Current

    Polymeric Materials High Voltage Tracking Index Leakage Current Plastic Test Machine IEC60587

    Technical Description:

    This product is used in electrical products under the influence of moisture and impurity environment, between the different polarity of the live parts or between the live parts and the grounding metal parts may cause insulation on the leakage, the resulting arc caused by electrical breakdown of the electrical or due to Discharge causes the material to erode and even ignite the fire.


    Standard:


    IEC60587.


    Parameters:


    Box

    ≥ 0.5 cubic meters

    Drop size

    44 to 50 drops / cm3

    Power supply

    AC 220V, 50Hz

    Electrical load

    100 ~ 600V adjustable

    Drip height

    30mm ~ 40mm adjustable

    Electrode Pressure

    1.00N±0.05N

    Flow range0.00185 to 2 ml / min
    Working speed0.1 to 15 rev / min



    Test voltage, series resistance and Pollution liquid flow rate table:


    Test voltage range(KV)Tracking recommend voltage (KV)

    Pollution liquid flow

    rate (ml/min)

    Series resistance


    1.0 ~ 1.75-0.0751
    2.0 ~ 2.752.50.1510
    3.0 ~ 3.753.50.3022
    4.0 ~ 4.754.50.6033
    5.0 ~ 6.0-0.9033

    Welcome to visit our factory for sightseeing!
